Link Split Ergo by CannonKeys - Group Buy

The Link split ergo is an upcoming keyboard project from us at CannonKeys that aims to fill a gap in the ergo market. We've designed our own wired PCB that uses an RP2040 with USB-C interconnectivity, a wireless ZMK PCB that allows for completely cableless user experience, and high profile CNC aluminum case that maintains compatibility with several OEM tenting solutions. There will also be tenting solutions designed by our team for link specifically that will be open sourced after the group buy.

Specs and Features

• Hotswappable large OLED screen (wired version) or optional nice!view (wireless)
• Rotary encoder module
• Hotswap wired (QMK/VIA) and wireless (ZMK Studio) MX PCBs
• Battery on host side (left) estimated to last 3-4 weeks on the 230mAh battery. Child side (right) will last much longer.
• USB-C interconnect, with a full/true wireless option also offered
• Aluminum screen cover
• Tray/gasket mount
• 1.2mm PCB
• 0° angle case
• Compatible with various OEM tenting solutions
• Proprietary & open source tenting base

 Wired Version Contents

• 1x 6063 aluminum left case
• 1x 6063 aluminum left wired cover
• 1x Left hotswap PCB including rotary encoder module
• 1x Right hotswap PCB including rotary encoder module
• 1x 6063 aluminum right case
• 1x 6063 aluminum right wired cover
• 2x Silver brass knob
• 2x Polycarbonate plate (reversible)
• 2x SH1107-powered OLED screens
• 12x Poron gaskets
• 8x 8mm bumpons
• USB-C to USB-C cable
• Assorted hardware and screws
• Microfiber cloth
• Hard carry case

Wireless Version Contents

• 1x 6063 aluminum left case
• 1x 6063 aluminum left wireless cover
• 1x Left wireless hotswap PCB including rotary encoder module
• 1x Right wireless hotswap PCB including rotary encoder module
• 1x 6063 aluminum right case
• 1x 6063 aluminum right wireless cover
• 2x Silver brass knob
• 2x Polycarbonate plate (reversible)
• 2x Acrylic insert for screen cover (black)
• 2x 230mAh battery (USA orders only)
• 12x Poron gaskets
• 2x Battery gasket
• 8x 8mm bumpons
• USB-C to USB-C cable (for ease of charging)
• Assorted hardware and screws
• Microfiber cloth
• Hard carry case

Nice!view screen is not included.
